Hassan Sheets is a reliable Riyadh, Saudi Arabia-based manufacturer and supplier of high-quality stainless steel angles that are renowned for their strength, durability, and resistance to corrosion. Produced to international standards, these angles are in different sizes and thicknesses to accommodate diverse structural and fabrication requirements. Hassan Sheets supplies industries that include construction, marine, automotive, and chemical processing with dependable materials that resist corrosive environments and heavy-duty use.
Stainless steel angles are typically produced from grades such as 304, 316, and 430, which have high resistance to oxidation, corrosion, and wear. The tensile strength of these angles is usually between 500 MPa and 620 MPa, with excellent weldability and formability. Their resistance to mechanical stress and moisture or chemical exposure ensures that they can be used either indoors or outdoors.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel angle have many advantages, making them popular in construction and manufacturing. They are very strong, corrosion resistant, and remain strong even in extreme temperatures. Stainless steel corners also make good aesthetic appeal due to their elegant design. Minimal maintenance is required, to ensure longevity. In addition, their versatility, ease of manufacture, and strength-to-weight ratio make them ideal for construction applications. Their resistance to harsh chemical and environmental conditions ensures reliability and efficiency in the automotive, marine and construction industries.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
Stainless steel angles are used extensively as structural supports, frames, braces, and reinforcements in buildings, bridges, machines, and equipment. They are also utilized in marine environments, food processing facilities, and chemical industries where corrosion resistance is paramount. Their strength, durability, and looks make them the favored option for engineers and architects looking for durable, low-maintenance materials for several construction and industrial projects.
