Hassan Sheets and Plate, based in Riyadh, Saudi Arabia, has built a solid reputation as a reliable manufacturer and supplier of high-performance metal products tailored for the toughest industrial environments. One of their standout offerings is the **Hastelloy B2 Sheet and Plate**, a nickel-molybdenum alloy celebrated for its exceptional resistance to reducing agents, particularly hydrochloric acid. These sheets and plates are crafted with durability, precision, and strength in mind, making them perfect for the chemical processing industry and similar fields. Hassan Sheets and Plate is committed to ensuring that all their products adhere to international standards, providing clients with dependable, long-lasting solutions for their most demanding and corrosive applications.
The **Hastelloy B2 Sheets and Plates** are primarily made up of nickel (around 69%) and molybdenum (approximately 28–30%), along with small amounts of iron, cobalt, and other elements. This unique alloy offers remarkable resistance to hydrochloric acid, hydrogen chloride, and other potent reducing chemicals. It boasts a tensile strength of about 760 MPa while maintaining good ductility and formability. Additionally, Hastelloy B2 is resistant to stress corrosion cracking and pitting, especially in pure, unoxidized acid environments. Its mechanical stability under pressure and temperature makes it an excellent choice for demanding chemical processing applications.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | ASME SB333, ASTM B333 UNS N10665, ASTM B333 UNS N010675, AMS, MSRR, BS |
| Length | 0-12mm or as required |
| Specification of ASTM B333 Alloy B2 Plate | ASTM B333 UNS N10665, ASME SB333, MSRR, BS, AMS 4544 sheet |
| Alloy B2 Plate Width | 0-2500mm or as required |
| UNS N10665 Plate Thickness | 0.3 to 1200 mm or as required |
| Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B333 Alloy B2 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Alloy B2 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.02 max | 26 – 30 | 1.00 max | 0.1 max | 2.0 max | 0.04 max | 0.03 max | 1.0 max | 1.0 max |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy B2 | 9.2 g/cm3 | 1370 °C (2500 °F) | Psi – 51000 , MPa – 350 | Psi – 1,10,000 , MPa – 760 | 40 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy B2 | N10665 | 2.4617 | – | – | – | – | – |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B2 sheets and plates offer exceptional advantages particularly in highly corrosive environments. Known for their superior resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals, they are ideal for chemical processing, storage, and handling systems. Their high strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking ensure long-lasting performance. Additionally, Hastelloy B2 provides outstanding weldability and formability making it easy to fabricate for complex applications. Its ability to maintain structural integrity under extreme conditions reduces maintenance and downtime, enhancing operational efficiency in industries such as pharmaceuticals, chemical and petrochemical.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
You’ll find **Hastelloy B2 Sheets and Plates** widely utilized in the chemical processing sector for constructing heat exchangers, reactors, pressure vessels, and storage tanks that deal with aggressive reducing acids. They’re also essential in the pharmaceutical and specialty chemical industries, where preventing contamination and corrosion is crucial. Plus, these plates are perfect for pickling operations and acid recovery systems. With their outstanding chemical resistance and mechanical integrity, Hastelloy B2 products guarantee long-term performance and safety in environments where traditional alloys might not hold up.
