Hassan Sheets and Plates is a reputable manufacturer and supplier of Monel Sheets and Plates based in Riyadh, Saudi Arabia. They offer top-notch nickel-copper alloy products that are well-known for their outstanding corrosion resistance, strength, and durability. Monel alloys stand out for their ability to resist seawater, acids, and alkalis, making them perfect for tough and demanding environments. At Hassan Sheets and Plates, they prioritize precision manufacturing and adhere to international standards, ensuring that their Monel Sheets and Plates are ideal for applications in chemical processing, marine, aerospace, and various industrial sectors where reliability and long-lasting performance are crucial.
The composition of Monel Sheets and Plates mainly includes nickel (usually 63–70%) and copper (28–34%), along with trace amounts of iron, manganese, carbon, and silicon. This blend gives them remarkable resistance to corrosion in both oxidizing and reducing environments, along with excellent mechanical strength and good toughness. In terms of mechanical properties, Monel Sheets and Plates boast a tensile strength between 550–750 MPa, yield strength of 200–400 MPa, and impressive elongation, coupled with excellent fatigue resistance and weldability, making them a great fit for demanding industrial applications.
Specifications :ASTM B127, ASME SB127, AMS 4544, QQ-N-281, DIN 17750, BS 3072NA1, BS 3076NA13
Standards : ASTM, ASME and API
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness : 0.1mm to 12 mm Thk
Length : 12500 mm
Form : Coils, Foils, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) & Angle, Channel, Tray Etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Plate, Sheet, and Strip : BS3072NA18 (Sheet and Plate), BS3073NA18 (Strip), QQ-N-286 (Plate, Sheet and Strip), DIN 17750 (Plate, Sheet and Strip), ISO 6208 (Plate, Sheet and Strip)
Grade : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Sizes in Inches | Sizes in mm |
|---|---|
| .125″ | 3.18mm |
| .134″ | 3.40mm |
| .156″ | 3.96mm |
| .187″ | 4.75mm |
| .250″ | 6.35mm |
| .312″ | 7.92mm |
| .375″ | 9.53mm |
| .500″ | 12.7mm |
| .625″ | 15.9mm |
| .750″ | 19.1mm |
| .875″ | 22.2mm |
| 1″ | 25.4mm |
| 1.125″ | 28.6mm |
| 1.250″ | 31.8mm |
| 1.500″ | 38.1mm |
| 1.750″ | 44.5mm |
| 2″ | 50.8mm |
| 2.500″ | 63.5mm |
| 3″ | 76.2mm |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in mm) |
| .125″ | 3.18mm |
| .134″ | 3.40mm |
| .156″ | 3.96mm |
| .187″ | 4.75mm |
| .250″ | 6.35mm |
| .312″ | 7.92mm |
| .375″ | 9.53mm |
| .500″ | 12.7mm |
| .601″ | 15.9mm |
| .750″ | 19.1mm |
| .875″ | 22.2mm |
| 1″ | 25.4mm |
| 1.125″ | 28.6mm |
| 1.250″ | 31.8mm |
| 1.500″ | 38.1mm |
| 1.750″ | 44.5mm |
| 2″ | 50.8mm |
| 2.500″ | 63.5mm |
| 3″ | 76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Monel Sheets and Plates offer numerous advantages, including exceptional corrosion resistance, especially in harsh environments like seawater, acidic, and alkaline solutions. They possess high strength, excellent weldability, and good formability, making them suitable for complex applications. Monel is resistant to stress corrosion cracking and oxidation, ensuring durability and reliability over time. The alloy also exhibits outstanding resistance to high-temperature environments, making it ideal for marine, aerospace, and chemical processing industries. With these superior properties, Monel Sheets and Plates provide long-term performance, reducing maintenance costs and enhancing the longevity of components and structures.
| Surface finish | Gauge (in) | Width (in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | max. 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Polished (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
These Monel Sheets and Plates find extensive use in the chemical and petrochemical industries for heat exchangers, evaporators, tanks, and reactor vessels, thanks to their resistance to acids and alkalis. In marine settings, they are utilized in seawater piping, desalination plants, and offshore equipment. The aerospace and power generation sectors rely on them for high-strength, corrosion-resistant components, while the oil and gas industry uses them in valves, pumps, and pressure vessels. With their unique blend of strength, corrosion resistance, and durability, Monel Sheets and Plates are a dependable choice for critical applications across a variety of industries.
