Hassan Sheets is a reputable Riyadh, Saudi Arabia-based manufacturer and supplier of premium sheet and plate solutions for industrial use. Renowned for its quality, accuracy, and customer satisfaction commitment, the organization is specialized in supplying Titanium Grade 2 sheets and plates. The products are highly acclaimed for their durability, corrosion resistance, and lightweight features. Hassan Sheets caters to various industries such as aerospace, marine, chemical processing, and the medical industry, with high-performance materials that are dependable and comply with international standards and harsh environmental conditions.
Titanium Grade 2 plates and sheets consist of commercially pure titanium, which is normally 99.2% titanium with minor amounts of iron, oxygen, carbon, nitrogen, and hydrogen. They possess excellent corrosion resistance, particularly in oxidizing conditions. Mechanically, they consist of tensile strength of approximately 344 MPa and yield strength of about 275 MPa with satisfactory ductility and formability. These characteristics make Titanium Grade 2 suitable for welding and cold forming, providing a strong but lightweight material that can withstand heavy-duty applications reliably.
| Specifications | ASTM B265/ ASME SB265 |
|---|---|
| Size | 1000 x 2000 milimeter, 1220 x 2440 milimeter, 1500 x 3000 milimeter, 2000 x 2000 milimeter, 2000 x 4000 milimeter |
| Thickness | 0.1 to 12 milimeter |
| Form | Plates, Sheet, Slatting Coils, Coils, Foils, Plain Sheet, Shim Sheet, Strip, Rolls, Perforated Coils, Flats, Blank , Ring |
| Finish | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade 2 Sheet & Plate | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 2 Sheet & Plate | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 sheets and plates offer excellent corrosion resistance, particularly in marine and chemical environments, making them ideal for aerospace, chemical processing, and marine industries. They are lightweight yet exceptionally strong, providing a high strength-to-weight ratio. Known for their biocompatibility, they are widely used in medical applications. Titanium Grade 2 also has good weldability, formability, and resistance to high temperatures, making it versatile for various applications. Additionally, it exhibits low thermal expansion, enhancing stability in challenging environments.
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in ) |
| .125 | 3.18 |
| .134 | 3.40 |
| .156 | 3.96 |
| .187 | 4.75 |
| .250 | 6.35 |
| .312 | 7.92 |
| .375 | 9.53 |
| .500 | 12.7 |
| .600 | 15.9 |
| .750 | 19.1 |
| .875 | 22.2 |
| 1 | 25.4 |
| 1.125 | 28.6 |
| 1.250 | 31.8 |
| 1.500 | 38.1 |
| 1.750 | 44.5 |
| 2 | 50.8 |
| 2.500 | 63.5 |
| 3 | 76.2 |
Titanium Grade 2 plates and sheets are extensively utilized in applications where corrosion-resistant strength and lightweight strength are required. Examples include pressure vessels, marine parts, chemical processing tanks, medical equipment, and heat exchangers. Their biocompatibility renders them appropriate for medical instruments and implants, whereas their strength favors long-term applications in industrial systems. The plates and sheets are also appreciated in aviation for structural parts because of their high strength-to-weight ratio. Their applicability in diverse industries makes them a material of choice for engineers and manufacturers.
