Hassan Sheets and Plates, based in Riyadh, Saudi Arabia, is a leading manufacturer and supplier of Duplex Steel Sheets and Plates. Known for exceptional strength, durability, and corrosion resistance, our Duplex Steel products are tailored to meet the rigorous demands of industries such as oil and gas, petrochemicals, and marine applications. With precision engineering and top-notch quality, we ensure reliable performance and long-lasting results. Trust Hassan Sheets and Plates for premium solutions that set the benchmark for excellence in the Saudi Arabia market.
Duplex Steel Sheets and Plates are made from a balanced blend of austenite and ferrite, incorporating 22-25% chromium, 4-6% nickel, 3-4% molybdenum, and controlled nitrogen levels. This unique composition provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. With a tensile strength of 620-850 MPa and a yield strength of approximately 450 MPa, Duplex Steel exhibits twice the strength of traditional stainless steel. Its excellent toughness and ductility make it a reliable choice for use in corrosive and high-pressure environments.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheets and Plates offer numerous advantages, including superior strength, high resistance to corrosion, and exceptional durability in aggressive environments. The combination of austenitic and ferritic microstructures provides enhanced resistance to stress corrosion cracking, pitting, and crevice corrosion. They are known for their high tensile strength, which makes them ideal for high-pressure and high-temperature applications. Additionally, Duplex Steel offers excellent weldability and formability, making it suitable for a wide range of industries, including oil and gas, chemical, marine, and structural applications. Its cost-effectiveness further adds to its appeal.
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex Steel Sheets and Plates are widely used across various industries due to their excellent strength and corrosion resistance. They are commonly employed in the oil and gas industry for offshore platforms, pipelines, and heat exchangers. In the chemical industry, they are used for reactors, tanks, and pressure vessels, thanks to their resistance to acidic environments. Marine applications, including shipbuilding and desalination plants, benefit from their durability in seawater. Duplex steel is also used in construction, power generation, and food processing, offering long-lasting performance in challenging conditions.
