Hassan Sheets and Plates is a well-known manufacturer and supplier based in Riyadh, Saudi Arabia, offering a wide array of stainless steel products, including Stainless Steel 410 Sheets and Plates. Renowned for their precision engineering, top-notch quality, and prompt delivery, Hassan serves various sectors like construction, petrochemical, power generation, and manufacturing. Stainless Steel 410 is a martensitic stainless steel that strikes a great balance between corrosion resistance and impressive strength and hardness. Hassan specializes in tailored sheet and plate solutions that adhere to international standards, ensuring they deliver performance, durability, and cost-effectiveness for a range of industrial uses.
The composition of Stainless Steel 410 Sheets and Plates primarily includes iron, with 11.5–13.5% chromium and 0.08–0.15% carbon. This martensitic alloy provides a solid mix of strength, hardness, and moderate corrosion resistance. In terms of mechanical properties, it boasts a tensile strength of 450–700 MPa, a yield strength of around 275 MPa, and hardness reaching up to 35 HRC. The 410 grade can be hardened through heat treatment, making it a great choice for wear-resistant applications. It also offers good machinability and fair weldability, making it perfect for situations where mechanical strength and moderate corrosion resistance are crucial.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Cr | Mn | Si | Ni | C | P | S | Fe |
| SS 410 | 11.50 – 13.50 | 0.0 – 1.50 | 0.0 – 1.00 | 0.0 – 0.75 | 0.08 – 0.15 | 0.0 – 0.04 | 0.0 – 0.02 | Balance |
| Tensile Strength Ksi (Mpa) | 0.2% Offset Yield Strength Ksi (Mpa) | Elongation, % in 2″ (51 mm) | Hardening Response HRC | HRB |
| 65 (450) – 74 (510) | 30 (205) – 42 (290) | 20 – 34 | 38-45 | 82-96 |
| Grade | WERKSTOFF NR. | UNS | AISI | BS | SIS | EN | JIS | AFNOR |
| SS 410 | 1.4006 | S41000 | 410 | 410S21 | 2302 | X12Cr13 | 410 | Z10C13/Z13C13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 410 sheets and plates offer a variety of benefits including excellent hardness and corrosion resistance, making them ideal for hard-wearing components such as cutlery, fasteners and valves especially in soft corrosive environments moderate corrosion resistance due to chromium content. Their high strength and durability enable them to be used in buildings and mechanical components. In addition, they can be heat treated, increasing the mechanical properties. Simple and affordable devices further enhance their appeal, making them a great choice for industries such as automotive, aerospace and construction.
Stainless Steel 410 Sheets and Plates find their place in various applications that demand high mechanical strength, hardness, and wear resistance. In the construction sector, they are utilized for structural components, roofing, and cladding. The petrochemical and power industries use them in heat exchangers, valve parts, and turbine components. They’re also great for cutlery, kitchen utensils, and industrial machinery. With their good machinability and moderate corrosion resistance, 410 sheets and plates are well-suited for both structural and functional applications where durability, formability, and toughness are key.
