Hassan Sheets and Plates stands out as a top-notch manufacturer and supplier of Stainless Steel 316 Sheets and Plates in Riyadh, Saudi Arabia. They pride themselves on delivering high-quality stainless steel products that are perfect for industries that demand exceptional corrosion resistance and durability. Stainless Steel 316 is a type of austenitic stainless steel enriched with molybdenum, which gives it an edge over standard grades by enhancing its resistance to pitting, crevice corrosion, and environments rich in chlorides. With a commitment to precision manufacturing and strict adherence to international standards, Hassan Sheets and Plates guarantees that their SS 316 Sheets and Plates are ideal for marine, chemical, petrochemical, pharmaceutical, and food processing sectors where strength, reliability, and longevity are crucial.
The composition of Stainless Steel 316 Sheets and Plates includes chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), with iron making up the rest, along with trace amounts of carbon, manganese, and silicon. The inclusion of molybdenum significantly boosts resistance to corrosion caused by chlorides. On the mechanical side, SS 316 boasts impressive tensile and yield strength, outstanding toughness, and good creep resistance, ensuring it maintains stability and performance in both high and low-temperature settings, making it a versatile choice for demanding applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 316 sheets and plates have many advantages, including exceptional corrosion resistance, especially in high chloride environments, making them ideal for marine and chemical applications They are extremely durable, . it has good strength, resistance to potholes, crack corrosion, and oxidation . It also provides excellent weldability, formability and toughness at high and low temperatures. Stainless Steel 316 is non-magnetic and resistant to extreme conditions, providing durability and reliability. These properties make it ideal for food processing, pharmaceutical, marine, and other industries.
These Stainless Steel 316 Sheets and Plates find extensive use in marine settings like shipbuilding, offshore platforms, and seawater piping, thanks to their excellent resistance to chlorides. In the chemical and petrochemical sectors, they are utilized in reactors, storage tanks, and processing equipment. The pharmaceutical and food processing industries rely on them for hygienic and sterile equipment due to their non-reactive nature. Additionally, they are employed in heat exchangers, power generation, pollution control systems, and architectural projects, providing remarkable durability, corrosion resistance, and long-lasting performance.
