Hassan Sheets and Plates is a reliable manufacturer and supplier of Stainless Steel 316H Sheets and Plates based in Riyadh, Saudi Arabia. They provide high-performance stainless steel products that are perfect for demanding industrial applications. Stainless Steel 316H is essentially the high-carbon variant of SS 316, crafted to deliver enhanced strength, creep resistance, and stress rupture properties, especially at elevated temperatures. With outstanding corrosion resistance in environments rich in chlorides and acids, Hassan Sheets and Plates guarantees that their SS 316H Sheets and Plates meet international standards, making them ideal for industries like petrochemical, chemical, power generation, and marine, where durability and longevity are crucial.
These Stainless Steel 316H Sheets and Plates are mainly made up of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), along with a higher carbon content compared to SS 316, and the rest is iron, with trace amounts of manganese, silicon, and nitrogen. The added carbon boosts high-temperature strength and structural stability. On the mechanical side, SS 316H showcases impressive tensile and yield strength, along with enhanced creep resistance and toughness at high temperatures, ensuring dependable performance even in harsh operating conditions.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 316H Sheet and Plates offers several key benefits, especially in high-temperature environments. Its high carbon content also increases creep resistance, making it ideal for structural application in the chemical, petrochemical and marine industries. The material boasts excellent corrosion resistance, especially against chloride, pitting and crevice corrosion. It also performs well in extreme temperatures, maintaining its integrity in high temperature conditions. In addition, stainless steel 316H is durable, easy to manufacture, and highly resistant to oxidation, providing long service life with minimal maintenance These properties make it ideal for environmental production difficult to destroy.
You’ll find Stainless Steel 316H Sheets and Plates commonly used in the chemical and petrochemical sectors for building pressure vessels, reactors, and heat exchangers that operate under high temperatures and corrosive conditions. In power plants, they’re utilized in boiler components, superheaters, and piping systems. The marine industry employs them for offshore platforms, seawater processing, and shipbuilding. Additionally, they’re used in food processing, pollution control systems, and pharmaceutical equipment, providing exceptional corrosion resistance, heat resistance, and long-lasting durability for critical applications.
