Hassan Sheets and Plates is a renowned manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in high-quality metal products for diverse industrial applications. We offer a comprehensive range of sheets and plates, including the SA537 Class 1 Boiler Sheet and Plate. These sheets and plates are known for their superior strength, durability, and resistance to high temperatures, which are ideal for pressure vessels and boilers. We are committed to providing products that meet the most stringent industry standards, ensuring top-tier performance and safety for our clients.
SA537 Class 1 is a normalized carbon steel alloy primarily used for pressure vessels and boilers. Its composition includes carbon (0.20–0.24%), manganese (0.60–0.90%), silicon (0.15–0.50%), phosphorus (≤0.035%), sulfur (≤0.035%), and small amounts of chromium and nickel to enhance strength. The mechanical properties of SA537 Class 1 include a tensile strength of 485–655 MPa, a yield strength of 275 MPa, and an elongation of 20% in 200mm. This steel offers excellent toughness and waterproof weldability and is ideal for high-pressure and temperature applications in power generation and chemical processing industries.
Grade : ASME SA 537 CL.1 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Yield (MPa) | Tensile (MPa) | Elongation | Thickness | |
| A50mm | A200mm | |||||
| SA537 Class 1 | Normalized | 345 | 485/620 | 22% | 18% | ≤ 65 |
| 310 | 450/585 | 22% | 18% | > 65 ≤ 100 | ||
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 1 Boiler Sheet and Plate offer excellent strength, toughness, and resistance to pressure, making them ideal for use in high-temperature and high-pressure applications like boilers and pressure vessels. Their superior weldability allows for easy fabrication, while their resistance to cracking and corrosion enhances reliability in demanding environments. This steel is heat-treated to ensure improved mechanical properties, long-term durability, and performance. With excellent formability and impact resistance, SA537 Class 1 is a trusted choice for power generation, petrochemicals, and manufacturing industries.
SA537 Class 1 boiler sheet and plate are primarily used in the construction of pressure vessels and boilers that operate under high-pressure and temperature conditions. They are highly valued in industries such as power generation, chemical processing, and oil and gas. The material’s excellent weldability, high tensile strength, and thermal fatigue and pressure resistance make it ideal for manufacturing components like reactor vessels, heat exchangers, and pressure tanks. It is also used to fabricate parts that require strength and durability under demanding conditions.
