Sailcor Corten Steel is a copper-chromium alloy steel specifically engineered to enhance resistance to atmospheric corrosion. Its typical makeup includes carbon (max 0.12%), manganese (0.20–0.75%), phosphorus (max 0.07%), sulfur (max 0.03%), copper (0.25–0.55%), and chromium (0.30–1.25%). This steel boasts a minimum yield strength of 340–450 MPa and a tensile strength ranging from 470–630 MPa, depending on its thickness. Sailcor plates are celebrated for their outstanding weldability and formability. Over time, a stable oxide layer develops on the surface, offering long-lasting corrosion resistance without the need for paint or coatings in most outdoor settings.
| Thickness | Width | Length |
|---|---|---|
| 3 to 500 mm | 1000 to 3500 mm | 1000 to 12000 mm |
| Process | Application | Form |
| hot and cold rolled | building facaded, railway wagons etc. | coil, plate, sheet |
| ASTM 588 GR A | IRSM 41 -97 | Corten – A Plates | ASTM 242 TYPE -1 | |
|---|---|---|---|---|
| Manganese | 0.80-1.25 | 0.25-0.45 | 0.20-50 | 1.00 |
| Carbon, Max | 0.19 | 0.10 | 0.12 | 0.15 |
| Phosphorus | 0.04 | 0.07-0.11 | 0.07-0.15 | 0.15 |
| Silicon | 0.30-0.65 | 0.28-0.72 | 0.25-0.75 | 0.25-0.40 |
| Aluminimum | … | 0.030 | – | – |
| Sulphur, max | 0.05 | 0.030 | 0.030 | 0.05 |
| Chromium | 0.40-065 | 0.30-0.50 | 0.50-1.25 | – |
| Nickel, max | 0.40 | 0.20-0.49 | 0.65 | – |
| Copper | 0.25-0.40 | 0.30-0.39 | 0.25-0.55 | 0.20 min |
| Molybdenum, max | – | – | – | – |
| Vanadium | 0.02-0.10 | 0.050 | – | – |
| Min. Yield Point | Tensile Strength | Elongation | |
| IRSM 41- 97 | [340 MPa] | [480 MPa] | 21% min |
| ASTM 588 GR. A | [345 MPa] | [485 MPa] | 21% min |
| CORTEN A | [355 MPa] | [470 – 630 MPa] | 20 % min |
| ASTM 242 TYPE -1 | [345 MPa] | [480 MPa] | 16% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hassan Sheets and Plates based in Riyadh, Saudi Arabia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for Sailcor Corten Steel Sheet and Plate to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Sailcor Corten Steel Sheets and Plates find extensive use in architectural facades, bridges, shipping containers, railway wagons, outdoor sculptures, and industrial structures where superior corrosion resistance is crucial. This material is especially prized in coastal, desert, and urban areas where it faces constant weather exposure. Its visual appeal, coupled with low maintenance requirements and a long service life, makes it a fantastic choice for both practical and decorative applications.
