Hassan Sheets and Plate Manufacturer and Supplier, based in Riyadh, Saudi Arabia, proudly offers top-notch **EN 9 Sheets and Plates** that are built to last. These sheets and plates are perfect for applications that demand high surface hardness, solid wear resistance, and moderate tensile strength. EN 9 is a medium carbon steel grade that finds its place in the automotive, engineering, and general fabrication sectors. At Hassan, we provide a variety of EN 9 plates and sheets in different thicknesses and sizes, ensuring they deliver reliable performance for industrial needs throughout Saudi Arabia and the GCC.
Typically, EN 9 Sheets and Plates have **0.5–0.6% Carbon and 0.7–1.0% Manganese**, which gives them great machinability and an excellent response to heat treatment. These plates boast a **tensile strength of 550–700 MPa** and can be flame or induction hardened to achieve impressive surface hardness. EN 9 steel is perfect for components that need strength and surface wear resistance, while also maintaining good toughness when faced with impact loading.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hassan Sheets and Plates based in Riyadh, Saudi Arabia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
You’ll find EN 9 Sheets and Plates commonly used in the production of **gears, shafts, axles, crankshafts, spindles, rollers, and various automotive parts**. Their hardening capability makes them ideal for **mechanical components that experience friction, torsion, and fatigue**. EN 9 offers a cost-effective solution for engineering applications that require enhanced strength and wear resistance, all without the need for additional alloying elements.
Yes, we offer custom sizes for EN 9 Sheet and Plates to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
EN 9 sheets and plates are commonly used in applications requiring high strength and corrosion resistance. They are ideal for making gears, shafts, axles and crankshafts, making them important in automotive engineering. EN 9 is used in heavy machine parts, spindles and equipment that are constantly wear and tear. Furthermore, it is suitable for construction materials such as poles, beams and bridge sides, where durability and durability are required. Its versatility makes EN 9 valuable where reliable and high-strength products are required.
