Hassan Sheets and Plate Manufacturer and Supplier, based in Riyadh, Saudi Arabia, proudly offers robust and high-performance **C50 High Carbon Steel Sheets and Plates**. These materials are perfect for industrial applications that demand superior strength, hardness, and wear resistance. C50 is recognized as a medium-to-high carbon steel grade, celebrated for its outstanding mechanical properties, making it a popular choice in engineering, automotive, and tooling industries. At Hassan, we provide C50 sheets and plates in various sizes and thicknesses to cater to the diverse needs of our clients throughout Saudi Arabia and the GCC.
Typically, C50 High Carbon Steel Sheets and Plates contain **0.47–0.55% Carbon** and **0.60–0.90% Manganese**, resulting in a **tensile strength of 600–750 MPa** after heat treatment. These plates are known for their good hardness, moderate machinability, and exceptional wear resistance. C50 is ideal for hardening and tempering processes, which enhance fatigue strength and structural integrity in dynamic applications. However, it’s worth noting that the high carbon content limits its weldability.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find C50 High Carbon Steel Sheets and Plates commonly used in **machine parts, automotive components, axles, gears, tools, cutting blades, crankshafts, and shafts**. Their **high hardness and abrasion resistance** make them perfect for situations where surface wear and mechanical stress are significant concerns. C50 steel offers a cost-effective, high-performance solution for heavy-duty and high-load-bearing applications.
Yes, we offer custom sizes for C50 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
C50 High Carbon Steel Plates are widely used in industries that require high strength and durability. They are commonly utilized in the manufacture of machine components such as gears, shafts, and axles, as well as cutting tools, dies, and molds. These plates are also ideal for constructing heavy-duty machinery, structural parts, and automotive components that must withstand significant stress and wear. C50 steel plates are used in applications involving high-load conditions, such as pressure vessels, industrial tools, and engineering structures, ensuring long-lasting performance in demanding environments.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
