Hassan Sheets and Plates is a well-respected manufacturer and supplier of Zirconium Sheets and Plates based in Riyadh, Saudi Arabia. We take pride in offering top-notch products specifically designed for specialized industrial applications. Zirconium is celebrated for its remarkable resistance to corrosion, particularly against harsh acids like hydrochloric and sulfuric acid, making it a dependable choice in challenging chemical environments. Our zirconium sheets and plates are crafted with precision to guarantee exceptional purity, strength, and durability. They find extensive use in chemical processing, nuclear power, and marine applications, all while adhering to global quality standards to ensure they perform reliably even in the toughest conditions.
These Zirconium Sheets and Plates are mainly made from zirconium metal, with a small percentage of hafnium—usually less than 4.5%—due to their similar chemical properties. The material is not only lightweight but also incredibly strong, providing excellent ductility, toughness, and resistance to stress-corrosion cracking. Zirconium maintains impressive mechanical stability at high temperatures, boasting a melting point that exceeds 1850°C. Additionally, it shows great biocompatibility, making it a suitable option for both medical and nuclear applications. With its outstanding resistance to acidic environments and a low neutron absorption cross-section, zirconium sheets and plates are a reliable choice for critical industrial operations.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hassan Sheets and Plates based in Riyadh, Saudi Arabia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Zirconium Sheets and Plates are incredibly popular in the chemical processing industry, where they’re used to build heat exchangers, reactors, pumps, and piping systems that come into contact with harsh chemicals. In the nuclear sector, they play a crucial role in cladding fuel rods, thanks to their low neutron absorption and impressive heat resistance. The marine industry also relies on zirconium for applications that demand durability in salty environments. Beyond that, you’ll find zirconium in aerospace, defense, and medical devices, all because of its remarkable strength, resistance to corrosion, and biocompatibility. It truly is a versatile material that meets the needs of various demanding fields.
Yes, we offer custom sizes for Zirconium Sheets and Plates to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Zirconium sheets and plates are widely used in industries requiring high corrosion resistance and durability. They are essential in nuclear reactors for fuel cladding due to their low neutron absorption. In the chemical industry, they are used for reactors, pipes, and valves exposed to aggressive acids. Zirconium’s biocompatibility makes it valuable in medical implants and dental applications. Additionally, it is used in aerospace for high-temperature components, as well as in military applications for its strength and resistance to harsh environments. These sheets and plates also find use in electronics and energy production.
