Hassan Sheets and Plate Manufacturer and Supplier, based in Riyadh, Saudi Arabia, stands out as a top provider of high-quality steel products specifically designed for pressure vessel and heat-resistant applications. Among their specialized products are the SA 204 Grade A and B Sheets and Plates, which are celebrated for their outstanding performance in high-temperature environments. These molybdenum-alloyed plates boast enhanced strength, corrosion resistance, and excellent weldability, making them perfect for boilers, pressure vessels, and various industrial equipment. Hassan is committed to adhering to ASTM standards, delivering precision-engineered materials that meet the rigorous demands of industries like petrochemicals, power generation, and oil refining throughout the Middle East.
SA 204 Grade A/B Sheets and Plates are crafted from molybdenum-alloyed carbon steel, specifically designed for high-temperature pressure vessel applications. Their composition features carbon (max 0.27%), manganese (0.90–1.50%), phosphorus (max 0.035%), sulfur (max 0.035%), and molybdenum (0.45–0.65%). These grades provide impressive mechanical strength and thermal stability. Grade A has a minimum yield strength of 220 MPa, while Grade B offers around 275 MPa. Both grades demonstrate tensile strength between 415 and 585 MPa, along with good ductility and weldability. They are typically supplied in either the as-rolled or normalized condition to enhance their structural integrity under thermal stress.
Standard: ASTM A204/ ASME SA204
Steel Grade: Grade B
Thickness: 6mm to 150mm
Length: 3000mm to 15000mm
Width: 1500mm to 4050mm
Delivery state: Hot Rolled
Surface: Mill Varnish, Oiled,Galvanized, Bare
Application: steel boiler plates, high temperature pressure vessel plates
| Grade | Chemical Composition(%) | ||||
| P | Mn≥ | C | Si | S | |
| ASTM A204 Grade B(A204GRB) | 0.035 | 0.98 | 0.20 | 0.13-0.45 | 0.035 |
| Mechanical Property | A204 Grade B |
|---|---|
| [MPa] Tensile strength, kis | 70-90 [485-620] |
| min, % Elongation in 2 in. [50 mm] | 21 |
| [MPa] Yield strength, min, kis | 40 [275] |
| min, % Elongation in 8 in. [200 mm] | 17 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hassan Sheets and Plates based in Riyadh, Saudi Arabia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for SA 204 GR A/B Sheet and Plates to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
SA 204 Grade A/B Sheets and Plates find extensive use in the construction of pressure vessels, boilers, heat exchangers, and high-temperature tanks. These plates are particularly suited for industries such as power generation, petrochemicals, refining, and thermal processing, where heat and pressure resistance is essential. Their remarkable weldability and thermal resistance make them ideal for welded structures and components that endure elevated temperatures over extended service periods.
