Hassan Sheets and Plate is a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in high-quality Inconel 625 Channels that are built to thrive in the toughest environments. These channels are celebrated for their remarkable resistance to corrosion, oxidation, and extreme temperatures, making them perfect for industries that demand durability and strength in harsh conditions. Crafted with precision and a commitment to global standards, Inconel 625 Channels deliver long-lasting performance, stability, and ease of use. We cater to various sectors, including aerospace, marine, chemical processing, and power generation, providing advanced solutions for critical engineering and structural needs.
The Inconel 625 Channel is primarily made up of nickel (at least 58%) and chromium (20–23%), along with notable amounts of molybdenum (8–10%) and niobium (3.15–4.15%). This unique composition gives it exceptional resistance to pitting, crevice corrosion, and stress-corrosion cracking. On the mechanical side, it boasts high tensile strength, excellent fatigue resistance, and toughness, even when exposed to high temperatures. The alloy maintains its structural integrity under thermal cycling and mechanical stress, while its good weldability and formability make it easy to fabricate. These characteristics make Inconel 625 Channels a reliable choice for both heavy-duty and precision engineering applications.
Specifications : ASTM B446 / ASME SB446
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hassan Sheets and Plates based in Riyadh, Saudi Arabia, is a leading supplier and stockist of high-quality metal products, including sheets, plates, coils, foils, angles, channels, circles, and slitting coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 625 channels offer several advantages, making them ideal for demanding applications. Their exceptional resistance to oxidation, corrosion, and high temperatures ensures long-lasting durability in extreme environments. The alloy’s high tensile strength, fatigue resistance, and excellent weldability make it suitable for aerospace, chemical, and marine industries. Inconel 625 also exhibits superior resistance to stress corrosion cracking and fatigue at elevated temperatures, allowing it to perform reliably in harsh conditions. Its versatility, strength, and resistance to various corrosive media ensure longevity and reduced maintenance costs in critical applications.
| Sizes (all Dimensions in milimeter) | Approx Weight Inconel 625 Channels (kilogram/meter) | Inconel 625 Channels Sizes (all Dimensions in milimeter) | Approx Weight Inconel 625 Channels (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes, we offer custom sizes for Inconel 625 Channel to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
In aerospace, Inconel 625 Channels are widely used in jet engines, turbine shrouds, and exhaust systems thanks to their outstanding heat and corrosion resistance. In the marine and offshore sectors, they find applications in seawater piping, risers, and structural components that face saltwater exposure. Chemical and petrochemical facilities utilize them in reactors, heat exchangers, and processing units that deal with aggressive chemicals. In power generation, they are essential in boilers, gas turbines, and nuclear reactors. Their strength, durability, and versatility make Inconel 625 Channels vital for high-performance industrial applications.
