Hassan Sheets and Plate, located in Riyadh, Saudi Arabia, stands out as a premier manufacturer and supplier of high-quality metal products tailored for critical industrial applications. One of their standout offerings is the **Hastelloy C276 Sheets and Plates**, a top-notch nickel-molybdenum-chromium alloy celebrated for its remarkable resistance to a variety of aggressive chemicals. Built to thrive in the toughest environments, these sheets and plates are perfect for industries like chemical processing, marine, and pollution control. Hassan Sheets and Plate prides itself on precision manufacturing, adherence to international quality standards, and prompt delivery to satisfy both local and global customers.
The **Hastelloy C276 Sheets and Plates** are primarily made up of nickel (around 57%), molybdenum (approximately 16%), chromium (about 15.5%), and iron (around 5%), along with small amounts of tungsten, cobalt, and vanadium. This alloy showcases outstanding resistance to strong oxidizing and reducing agents, including chlorides and acidic solutions. It boasts a tensile strength ranging from 760 to 850 MPa, along with good ductility and weldability. Hastelloy C276 retains its mechanical integrity even under high temperatures and pressure, making it a go-to choice for environments prone to extreme corrosion that require long-lasting durability and strength.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 – ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 0-12mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 0-2500mm or as required |
| Plate Thickness | 0.3 to 1200 mm or as required |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Grade | C | Mn | And | S | Co | In | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000, MPa – 790 | Psi – 52,000, MPa – 355 | 40 % |
| Material | Ultimate Tensile (min) | Yield Strength (Min) | Elongation % | Hardness Rb | ||
|---|---|---|---|---|---|---|
| Ksi | Mpa | Ksi | Mpa | |||
| C276 Plate | 107.4 | 741 | 50.3 | 347 | 67 | 89 |
| C276 Sheet | 115.5 | 796 | 54.6 | 376 | 60 | 86 |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy C276 sheets and plates offer exceptional advantages, making them ideal for challenging industrial environments. They provide outstanding resistance to a wide range of corrosive media, including strong oxidizers, reducing agents, and chlorides, minimizing the risk of pitting, crevice corrosion, and stress corrosion cracking. Their high-temperature strength and excellent weldability ensure reliability in critical applications, such as chemical processing and marine systems. Additionally, Hastelloy C276 maintains superior performance in both acidic and alkaline environments, offering durability, extended service life, and reduced maintenance, even under extreme conditions, enhancing operational efficiency and safety.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
You’ll find **Hastelloy C276 Sheets and Plates** widely utilized in the chemical processing sector for reactors, heat exchangers, scrubbers, and tanks that come into contact with harsh chemicals like hydrochloric, sulfuric, and nitric acids. In marine settings, they’re used in seawater handling systems, providing excellent resistance to pitting and crevice corrosion. They also play a role in pulp and paper processing, pollution control equipment, and waste treatment facilities. With their superior corrosion resistance and mechanical stability, Hastelloy C276 is indispensable for industries that demand high performance in aggressive, high-stress environments.
