Hassan Sheets and Plate, based in Riyadh, Saudi Arabia, has built a solid reputation as a manufacturer and supplier of top-notch metal products, serving industries that require exceptional strength and resistance to corrosion. One of their standout products is **Duplex Steel S32205 Sheets and Plates**, a nitrogen-enhanced duplex stainless steel celebrated for its remarkable resistance to stress corrosion cracking, impressive mechanical strength, and long-lasting durability. These sheets and plates find extensive use in marine, chemical processing, oil & gas, and desalination sectors. At Hassan Sheets and Plate, they prioritize precise fabrication and adhere to international quality standards to ensure reliable performance in challenging and high-pressure environments.
**Duplex Steel S32205 Sheets and Plates** are made up of about 22% chromium, 5–6% nickel, 3% molybdenum, and a touch of nitrogen. This unique blend creates a balanced microstructure of austenite and ferrite, giving them double the strength of regular austenitic stainless steels. These sheets boast a tensile strength of around 620 MPa and good yield strength, along with excellent resistance to pitting, crevice corrosion, and chloride-induced stress corrosion cracking. The alloy also offers strong weldability and impact toughness, making it perfect for demanding structural and corrosive applications.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205 offer a combination of high strength and excellent corrosion resistance, making them ideal for harsh environments. Their balanced microstructure of austenite and ferrite enhances resistance to stress corrosion cracking, pitting, and crevice corrosion. With superior mechanical properties, including high tensile strength and yield strength, S32205 is highly durable and reliable. These plates also offer excellent weldability and formability, making them versatile for various industrial applications such as chemical processing, offshore, and marine industries. They provide a cost-effective alternative to more expensive high-alloy steels in demanding conditions.
Yes, we offer custom sizes for Duplex Steel Sheet and Plates S32205 to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
You’ll often find **Duplex Steel S32205 Sheets and Plates** in pressure vessels, heat exchangers, storage tanks, and piping systems across the chemical, petrochemical, and oil & gas industries. They’re also a go-to choice in marine environments and desalination plants, thanks to their ability to withstand chloride-rich conditions. These plates are prized for their blend of high strength and corrosion resistance, making them ideal for structural applications where being lightweight, durable, and having a long service life is crucial, whether in offshore or onshore industrial settings.
