Hassan Sheets and Plate Manufacturer and Supplier, located in Riyadh, Saudi Arabia, stands out as a top-notch provider of premium metal products, known for their reliability and durability across a range of industrial sectors. We take pride in our Copper Nickel 90/10 sheets and plates, celebrated for their remarkable resistance to corrosion and impressive mechanical strength. Crafted to meet international standards, our products are perfect for applications in the marine, oil & gas, and power industries. With a strong focus on precision, performance, and customer satisfaction, Hassan guarantees that every product offers lasting value, even in the toughest operating conditions.
Our Copper Nickel 90/10 (UNS C70600) sheets and plates are made up of about 90% copper and 10% nickel, with a touch of iron and manganese to boost strength and corrosion resistance. This alloy is not only easy to weld and form but also stands up well against seawater corrosion and biofouling. With a tensile strength of around 45 ksi (310 MPa) and a yield strength of 15 ksi (105 MPa), along with good ductility and thermal stability, it’s a fantastic choice for both structural and pressure-containing marine applications.
| Specifications | : | ASTM / ASME SB122 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Copper Nickel 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Copper Nickel 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel 90/10 | 2.0872 | C70600 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 90/10 sheets and plates offer exceptional corrosion resistance, especially in seawater and marine environments, making them ideal for shipbuilding and offshore applications. Their high strength and excellent formability ensure durability in challenging conditions. These materials are also resistant to biofouling, reducing maintenance needs. The alloys exhibit good thermal conductivity, making them effective in heat exchange systems. Additionally, Copper Nickel 90/10 sheets and plates provide excellent weldability, ensuring easy fabrication for various industrial uses. Their resistance to oxidation and stress corrosion enhances their reliability and longevity.
You’ll find Copper Nickel 90/10 sheets and plates in industries that require exceptional resistance to seawater corrosion and biofouling. They’re commonly used in shipbuilding, marine piping, condenser tubes, seawater intake systems, and offshore oil and gas structures. Additionally, these plates are essential in power generation facilities and desalination plants, thanks to their thermal conductivity and strength under pressure. Their reliability and resistance to stress corrosion cracking make them ideal for heat exchangers, cooling systems, and other equipment that faces harsh and saline environments.
