Hassan Sheets and Plates stands out as a top-notch manufacturer and supplier of Aluminium 2024 T3511 Plates and Sheets in Riyadh, Saudi Arabia. They pride themselves on delivering high-quality aluminum products that are built for strength, durability, and precision in various applications. Aluminium 2024 T3511 is a robust aluminum-copper alloy, well-known for its impressive fatigue resistance, machinability, and exceptional mechanical properties. The T3511 temper takes it a step further by boosting its toughness and stress resistance, making it a reliable choice for demanding engineering and structural tasks. At Hassan Sheets and Plates, they strictly follow international quality standards, ensuring that their Aluminium 2024 T3511 Plates and Sheets are perfect for industries like aerospace, automotive, marine, and defense.
These plates and sheets primarily consist of aluminum, with copper (3.8–4.9%) being the main alloying element, along with trace amounts of magnesium, manganese, silicon, and iron. The T3511 temper is achieved through a careful process of stretching and stress-relieving, which enhances dimensional stability and mechanical strength. In terms of performance, these plates and sheets boast excellent tensile and yield strength, high fatigue resistance, and good fracture toughness, although they do need protective coatings in corrosive environments.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 2024 T3511 Sheets and Plates offer outstanding advantages, including exceptional strength and fatigue resistance, making them ideal for high-performance aerospace, military, and engineering applications. The T3511 temper enhances the material’s structural integrity, ensuring reliability in demanding environments. These sheets and plates feature an excellent strength-to-weight ratio, critical for weight-sensitive industries like aviation. Their superior machinability allows for precise fabrication and complex designs. While the alloy has moderate corrosion resistance, it can be treated for enhanced durability, ensuring long-lasting performance. Aluminium 2024 T3511 is a top choice for high-stress applications.
Yes, we offer custom sizes for Aluminium 2024 T3511 Plates and Sheets to meet specific project needs. Our team at Hassan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Aluminium 2024 T3511 Plates and Sheets find extensive use in aerospace applications, such as aircraft fuselage, wings, and structural components, thanks to their outstanding strength-to-weight ratio. In the automotive industry, they are utilized in engine parts, body structures, and suspension systems. The defense sector employs them for armored vehicles, precision tools, and essential equipment. Additionally, they play a vital role in marine and engineering applications, including shipbuilding and high-performance machinery. With their remarkable mechanical properties and reliability, Aluminium 2024 T3511 Plates and Sheets are the go-to choice for high-performance and safety-critical applications.
